Current Injection Probe

BCIP-200

The BCIP-200 Current Injection Probe complies with MIL-STD-461E/F/G CS114, CS115, CS116, ISO 7637-3.

Request a Quote Add to Compare Add to Quote List

Introduction

The BCIP-200 Current Injection Probe complies with MIL-STD-461E/F/G CS114, CS115, CS116, ISO 7637-3. It transfers harmonic current signals or pulse current signals to the EUT via magnetic coupling.

The BCIP-200 features distortion-free waveform transmission and physical isolation from the EUT, and is widely used for conducted susceptibility (immunity) testing in electromagnetic compatibility (EMC) applications.


BCIP-200 Insertion Loss Curve

Features

> Undistorted waveform, physical isolation from EUT

> Frequency range 10 kHz ~ 200 MHz

> Max. Input Power 200W (continuous for 5 min)

Standards

Other Standards

MIL-STD-461G

Application Areas

Specification

Technical Parameters

Frequency Range	10 kHz ~ 200 MHz
Max. Input Power	100 W (continuous for 30 min)
	150 W (continuous for 15 min)
	200 W (continuous for 5 min)
Interface Type	N type
Height	90 mm
Inner Diameter	40 mm
Outer Diameter	127 mm
Weight	Approx. 3.12 kg

Optional Accessories

BCICF-200

Current Injection Probe Calibration Fixture
